RENDER

Hardware configured for peak performance from the following software applications:

•Arnold • SolidWorks •

Traditional CPU-based rendering is more likely to deliver higher image quality & clearer images devoid of 'noise'. GPU-based rendering is faster, involves significantly lower hardware costs and eliminates the need for multiple machines to produce professional quality work. GPUs offer superior memory bandwidth, processing power, and the speeds necessary to tackle tasks requiring multiple parallel computations & large caches of data.

Please Note: Render Software Applications determine the degree of CPU / GPU utilization.

All workstations meet or exceed software manufacturer minimum supported hardware configurations

AMD RYZEN 9 16-CORE WORKSTATION

AMD RYZEN 9 16-CORE WORKSTATION

  • 3.5GHz AMD Ryzen 9 3950X 16-Core CPU (All Cores to 4.2GHz)
  • Windows 10-Pro 64-bit OS
  • 128GB DDR4 3200MHz RAM
  • 1TB NVMe M.2 2880 OS Drive
  • 1x GeForce RTX2080Ti 11GB GPU
AMD THREADRIPPER 32-CORE WORKSTATION

AMD THREADRIPPER 32-CORE WORKSTATION

  • 3.7GHz AMD Threadripper 3970X 32-Core CPU
  • Windows 10 Pro 64-bit OS
  • 128GB (4x32GB) DDR4 3200MHz RAM
  • 1TB NVMe M.2 2880 OS Drive
  • 1x GeForce RTX2080Ti 11GB GPU
HP-Z8-G4-32-CORE-WORKSTATION

HP Z8 G4 32-Core Workstation

  • 2x 2.9GHz Intel Xeon 16-Core 6226R CPU (Turbo-Boost to 3.9GHz)
  • Windows 10 Pro 64-bit OS
  • 128GB DDR4 2933MHz ECC RAM
  • 1TB NVMe M.2 2880 OS Drive
  • 1x Nvidia GeForce RTX2080Ti 11GB GPU
HP Z840 20-CORE WORKSTATION

HP Z840 20-CORE WORKSTATION

  • 2X 3.1GHz Intel Xeon 10-Core E5-2687Wv3 CPU (Turbo-Boost to 3.5GHz)
  • Windows 10 Pro 64-bit OS
  • 128GB DDR4 2133MHz ECC RAM
  • 1TB NVMe M.2 2880 OS Drive
  • 1x GeForce RTX2080Ti 11GB GPU
Dell PowerEdge R610 CPU Render Node

DELL POWEREDGE R610

  • 1RU Rackmount 12-Core CPU Render Node
  • 2x Intel Xeon X5650 2.7GHz 6-Core Processors (Turbo Boost to 3.1GHz)
  • 128GB DDR3 1333MHz ECC RAM
  • 500GB Dell Disk Drive
  • iDRAC6 Enterprise Management
  • 4x QLogic BCM5709C 1GbE Ethernet
  • 2x Dell 500W Energy Smart Power Supply

Hardware configurations designed to provide peak performance from the following applications:

• Reality Capture • Octane • Redshift • Unreal Engine • V-Ray •
These software applications offer increased performance through the use of multiple GPUs.

AMD RYZEN 7 8-CORE WORKSTATION

AMD RYZEN 7 8-CORE WORKSTATION

  • 3.9GHz AMD Ryzen 7 3800XT 8-Core CPU (All Cores to 4.2GHz)
  • Windows 10-Pro 64-bit OS
  • 64GB DDR4 3200MHz RAM
  • 1TB NVMe M.2 2880 OS Drive
  • 2x GeForce RTX2080Ti 11GB GPU
AMD RYZEN 9 16-CORE WORKSTATION

AMD RYZEN 9 16-CORE WORKSTATION

  • 3.5GHz AMD Ryzen 9 3950X 16-Core CPU (All Cores to 4.2GHz)
  • Windows 10-Pro 64-bit OS
  • 128GB DDR4 3200MHz RAM
  • 1TB NVMe M.2 2880 OS Drive
  • 2x GeForce RTX2080Ti 11GB GPU
AMD THREADRIPPER 32-CORE WORKSTATION

AMD THREADRIPPER 32-CORE WORKSTATION

  • 3.7GHz AMD Threadripper 3970X 32-Core CPU
  • Windows 10 Pro 64-bit OS
  • 128GB DDR4 3200MHz RAM
  • 1TB NVMe M.2 2880 OS Drive
  • 2x GeForce RTX2080Ti GPU
HP-Z8-G4-32-CORE-WORKSTATION

HP Z8 G4 32-Core Workstation

  • 2x 2.9GHz Intel Xeon 16-Core 6226R CPU (Turbo-Boost to 3.9GHz)
  • Windows 10 Pro 64-bit OS
  • 128GB DDR4 2933MHz ECC RAM
  • 1TB NVMe M.2 2880 OS Drive
  • 2x Nvidia GeForce RTX2080Ti 11GB GPU
HP Z840 20-CORE WORKSTATION

HP Z840 20-Core Workstation

  • 2X 3.1GHz Intel Xeon 10-Core E5-2687Wv3 CPU (Turbo-Boost to 3.5GHz)
  • Windows 10 Pro 64-bit OS
  • 128GB DDR4 2133MHz ECC RAM
  • 1TB NVMe M.2 2880 OS Drive
  • 2x GeForce RTX2080Ti 11GB GPU
